Complete IN-House Pattern & Tool Making Facilities
Software & Autocad, Solid works. Cam (Dellcam)
- Tools & Cutter Grinders
- Surface Grinders
- Cylindrical Grinders
- Lathe Machine 6'
- Lathe Machine 8'
- Lathe Machine 10'
- Radial Drilling Machine
Core Making Facilities
- Sodium Silicate /Co2 Core Process Turnout Type Shell Core Shooter
- No Bake Core Process
Sand Preparation
- Intensive sand mixture with auto dosing of all additives, automatic sand temperature and sand moisture monitoring
- Italian Make Automatic Sand Dryer Plant
Molding Facility
Green Sand Molding
- Molding Machine 300 ARPA - 02 Nos.
- Molding Machine 450 ARPA - 06 Nos.
- Molding Machine 600 ARPA- 02 Nos.
- Molding Machine 900 ARPA - 02 Nos.
- Molding M/C- 1200 ARPA - 02 Nos
Molding Machine
BMM WESTON MODEL QJS 230
- Moulding Machine No. 2.09
- Squeeze Pressure - 90 Lb PS.I. 28.85 K.G.
- Jolt Capacity at - 90 Lb PS.I. 2.722 K.G.
- Pattern Draw - 406 mm
- Plate Adjustment - 406mm
- Squeeze Stroke - 305 mm
- Consumption Per Average Cycle - 2.69 cum
- Net Weight - 12076 K.G.
- Table Size - 1210 x 2180 mm
NO BAKE PROCESS
- No Bake (ALPHA-SET chemical based sand processing)
- Continuos sand mixture with capacity of 7 ton/Hr.
Sodium Silicate Molding Process (CO2)
Melting Section
- Medium Frequency Induction Furnace Capacity 500 Kg. - 02 Nos
- Medium Frequency Induction Furnace Capacity 1000 Kg - 02 Nos
- Gear Bottom & Pouring Ladles - 04 Nos
- Immersion Pyrometer - 04 Nos
- Online CE Metre - 02 Nos
- Cupola size Of die - 01 Set
Feltting & Finishing
- Shot Blasting Machine (Hanger Type) - 03 Nos.
- Shot Blasting Machine (Belt Type) - 02 Nos.
- Pneumatic Chippers - 03 Nos.
- Portable Grinders AG 9 - 10 Nos.
- Portable Grinders AG 7 - 20 Nos.
- Portable Grinders AG 5 - 20 Nos.
- Portable Grinders AG 4 - 10 Nos.
- Portable Grinders AG 2 - 05 Nos.
- Portable Grinders (Hanger Type) - 08 Nos.
- Flexible Shaft Grinder - 05 Nos.
- Pencil Grinder - 10 Nos.
Machining Facility
- HMC 2000x1200x1200 DAEWOO ACE H-100
- HMC 1350x1000x1000 DAHLIH MCH-800
- HMC 1025x800x750 mm (Mori Seki)
- HMC 550x500x550 mm- 02 nos (MAKINO)
- CNC Vertical Machining Centre 750x400x450mm (FANUC System)
- CNC Turning Centre 100x900 mm (FANUC System)
- CNC Turning Centre 400x650 mm (FANUC System)
- CNC Turning Centre 670x150 mm (FANUC System)
- VTL BFW BVL 700H - 02 No.
